Oil and Gas Process Design 34 Excel Spreadsheets

While Academia can sometimes lack focus on meeting Industry standards, engineering graduates are often left behind in picking up the requisite skills as demanded by the Process Design Industry. With an aim to bridge some of the gaps between academia and the industry, the following tutorial book aims to provide a practical approach and guide young chemical engineers in areas of Process Engineering Design through a series of learning modules with an
emphasis on Design Standards.

The spreadsheets cover the following chapters in the Selected Topics in Oil & Gas Process Design for Graduate Engineers book:

1 Chemical Process Calculations (Sheet 1 and Sheet 2)

2 Operating Envelopes for Centrifugal Pumps

3 Performance Curves of Centrifugal Pumps in the Absence of OEM Data (same as 4)

4 Affinity Laws for Variable Speed Centrifugal Pumps

8 Centrifugal Compressor Settle Out Conditions

9 Gas Compression Stages – Process Design & Optimization (with Hysys files)

10 Design Considerations for Compressor Antisurge Valve Sizing (with Hysys files)

11 Process Design for Natural Gas Transmission

13 Boil off Gas Analysis of LNG at Receiving Terminals

14 Gas Condensate Separation Stages – Design & Optimization (with Hysys files)

15 Process Design for Instrument Air Systems

17 Process Safety Valve (PSV) Sizing – API 520/521/526

19 Natural Gas Pipeline Transmission Cost and Economics

20 Evaluating Pipeline Operational Integrity – Sand Production

21 Economic Insulation for Industrial Piping

23 Flash Steam and Steam Condensates in Return Lines

24 Single Phase Liquid Vessel Sizing for HYSYS Dynamics

25 Key Thermo-Physical Properties of Light Crude Oils

26 Evaporation Pond Process Design in Oil & Gas Industry

27 Exploring LPG Cylinders for Medical Oxygen – A Preliminary Study

28 Heating Value Estimation for Natural Gas Applications

29 Empirical Approach to Hydrate Formation in Natural Gas Pipelines

31 Concrete Coating for Natural Gas Pipelines

33 Estimating Temperature Rise in Pump Recycle Lines

35 Cooling Tower Makeup Water Estimation

36 Pressure Relief Valve Design – A Short Tutorial

41 Makeup Water Estimation in Natural Gas Sweetening Units (Aspen Hysys V11 file)

42 Process Design of Industrial Deaerators

43 Process Design of Industrial Desuperheaters (Excel spreadsheet + Aspen Hysys V11 file)

44 Estimating Instrument Air Requirements

45 Netback Pricing Analysis for Gas Oil Separation Unit

46 SIL Verification for High Integrity Pressure Protection System

47 Atmospheric and Low Pressure Storage Tank Venting

48 Two Phase Vertical Separator Sizing – API 12J

49 Relief Valve Sizing for Two Phase Flow – API 520, Part 1 (Excel spreadsheet + Aspen Hysys V11 file)

ATTENTION: THIS PRODUCT IS NOT REFUNDABLE.

PS. All calculations are in SI.
